This video explains how different drive technologies used in micro-positioning, nanopositioning and precision automation work - by PI. // Contents:
Piezo Motors 0:05
Piezo Nanopositioners: 3:01
Linear Motors and Gantries: 4:23
Tools for Super Resolution Microscopy: 5:49
SiP - Photonics Alignment Technologies 7:22
About PI: 9:17
Whitepapers and Technotes https://www.pi-usa.us/en/te...
Broadest & Deepest Portfolio of Precision Motion and Automation Technologies
PI is a global leader in precision motion and automation technologies, including linear motors, piezo motors and mechanisms, hexapod 6-axis parallel kinematic alignment platforms, air bearing gantries; hybrid drives, multi-axis nanopositioning systems.
These stages are capable of providing nanometer size steps and below. PI offers different concepts for different applications, from ultra-precise and fast flexure stages for small travel ranges to large air bearing stages and exotic maglev systems.
Gantries, Linear Motors, Precision Air Bearing Stages, Components, Systems
Air bearing motion systems with linear motors provide frictionless motion with excellent guiding precision (flatness/straightness) over long travel ranges, and with high load capacity. PI's air bearing stage designs are based on more than 200 man years of experience.
Hexapod 6-Axis Positioners and Motion Platforms (Stewart Platforms)
Hexapod parallel positioners provide extremely versatile multi-axis motion in all degrees of freedom. They are based on a 6-axis (XYZ, Pitch, Roll, Yaw) actuator system, arranged in parallel between a top and bottom platform. PI Hexapod positioners and motion simulators have many advantages over conventional multi-axis stages, such as improved dynamics, smaller package size and higher stiffness.
Piezo Mechanisms: Stages & Positioners, Flexure Direct Drives, Piezo Motor Long Travel Designs
Several piezo-based positioning concepts: Flexure-guided stages provide the highest precision and speed, but are limited to typically to 1 mm travel range. Several piezo motor concepts are offered for long travel ranges. Ultrasonic piezo motors provide higher speed, PiezoWalk motors excel in force generation, and stick-slip motors are very compact and cost effective.
Precision Automation Stages and Actuators
A large variety of linear and rotary stages and actuators for precision automation is available. Several drive technologies: 3-phase electromagnetic motors, voice coil linear motors provide high speed long travel and long service life. Custom gantry systems with mechanical bearings and air bearings are available.
Photonics Alignment, Automated Fiber Positioners
Fiber alignment / photonics test automation systems come in different flavors from compact XYZ motorized fiber positioners to fully automated 6 degree of freedom hexapod alignment systems with controller and software. Integrated closed-loop piezo scanners provide extremely fast response for the shortest possible alignment times.
Digital Controllers / ACS Automation Controllers
Closed-loop positioning and motion controllers for piezo systems and linear motors are the key to high performance motion. PI provides a very large spectrum, from miniature OEM modules, to compact digital-servo bench top controllers. High-end multi-axis controllers based on ACS modules with EtherCat® connectivity with advanced servo algorithms.
