  • SR# 1-9638124541 - Videos 1 to 26 Play all

    SR# 1-9638124541 - Beveled Takeoffs Look Different
    PROBLEM STATEMENT: When a branch diameter is close or equal to the main, our beveled, conical or bell mouth takeoff, in AutoCAD MEP 2009 and newer versions, look different than in 2008 and earlier versions. From 2009 onwards, they show a contour sticking up from the side of the main.
    SOLUTION: Watch Video(s) 1 to 26
    This item has been hidden
  • SR# 1-5029725481 - Videos 1 to 20 Play all

    SR# 1-5029725481 - How to use Content Builders - Parametric Part Builder
    PROBLEM STATEMENT: We want to learn how to make Parametric MvParts and cannot find a lot of material on the topic. How do we use Parametric Part Builder? The original customer case gave us a sample part to make. It is a 40RM Packaged Air Handler made my Carrier.
    SOLUTION: Watch Video(s) 1 thru 20
    This item has been hidden
  • SR# 1-3318178871 - Videos 1 to 10 Play all

    SR# 1-3318178871 - Device Block Creation
    PROBLEM STATEMENT: Creating a device or symbol, or most anything annotative in AutoCAD MEP can be confusing. When we insert our custom device, the symbol comes in huge or too small. How do we get it to scale correctly with the Annotative scale?
    SOLUTION: Watch Video(s) 1 thru 10
    This item has been hidden
