This particular internal system assures 3 pawls engage while the other series of 3 pawls wait to engage. Drag has been reduced with fewer engagement points. Pawl life expectancy is also increased.
- 6 Pawls
- 51 Tooth Engagement Ring
- 102 Engagement Points
- 3.53 Degrees of Engagement
The Thrust hub utilizes a massive thrust bearing that permits rotation between the shell & the cog carrier/driver while supporting axial load, which makes for a dreamy smooth rotation. For the most part the entire series of Thrust hubs can be disassembled mostly without tools, allowing for easy access to maintain the hub(s). Guards press-on. Oversized bearings throughout.
14 mm RHD 9t rear w/extended axle
15 mm thru axle rear w/16t cog (Shimano lock-ring system)
3/8" bolt-on rear w/16t cog (Shimano lock-ring system)
3/8" bolt-on front
Press-on Hub Guards for easy install available for front and rear Thrust Hub(s)
Visit www.alienationbmx.com for more information.
