• korg monotron usb power mod

    1,447 views 4 years ago
    powering the korg montron via usb can be done with a simple voltage divider

    information here :

    Three 1N4001 diodes in series;

    USB 5V-------- 1N4001 diode+1N4001 diode+1N4001 diode=2.9V

    The standard USB A plug (left) and B plug (right)
    Pin 1 VCC (+5 V) ----this one
    Pin 2 Data-
    Pin 3 Data+
    Pin 4 Ground --- this one Show less
