OreTek MicroMill - Added XYBore command
osirusoft1
11 views
This command allows for one line of text to define a matrix of boring operations.
-
OreTek MicroMill - Added Radial Facing
osirusoft1
5 views
As a part of a project, I found it necessary to make it easier to create channels around a radius. Rface does just that.
-
OreTek MicroMill - Radial drilling and Radial boring of 24 holes 15 degrees apart.
osirusoft1
11 views
In the process of making a test fixture, I decided to add a bore command that works in much the same way as the rdrill (Radial drilling) command. All of the 5/16" counter ...
-
OreTek - MAG (Multi-Axis-Generator) disks/gears combined.
osirusoft1
44 views
This is a part of a magnetic motor design, syncronized directly, this time, with the disks themselves being 2 of the 3 gears. The outside of the disk is 38 teeth designed ...
-
OreTek MAG (Multi-Axis-Generator) Top/Bottom pieces
osirusoft1
14 views
This is the process for creating the top and bottom pieces of the mult-axis generator. These parts are constant for a 2 shaft version, while the side panels vary in accord...
-
Multi-Axis-Generator enclosure elbow manufacturing.
osirusoft1
17 views
This is the manufacturing process for the enclosure elbows for all versions of the multi-axis-Generator, an experiment in the creation of a magnetic motor. Details for this...
-
OreTek MicroMill - Manufacturing a 24 tooth gear.
osirusoft1
95 views
For a specific application, I needed gears and thought I'd try my hands at making my own gear. I added a "COG" command
cog x,y,z1,z2 depth1,depth2 number_of_teeth.
...
-
MAG (Multi-Axis-Generator) Disks/spacers Part 3 of 3
osirusoft1
8 views
This stage creates spacers and finishes the manufacturing process of the disks that hold the magnets.
All specifications for this design are intentionally published with ...
-
MAG (Multi-Axis-Generator) Disks/spacers Part 2 of 3
osirusoft1
4 views
Manufacturing process for the MAG. This stage drills 13/64" holes to later be tapped 1/4-20. Stainless Steel screws will be used due to magnetic fields.
All specificatio...
-
MAG (Multi-Axis-Generator) Disks/spacers Part 1 of 3
osirusoft1
7 views
Manufacturing process for the MAG. This stage creates pockets for 1/2x1/2 cylindrical magnets, 12 per disk, sandwiched between 2 HDPE sheets.
