Specifications for Fractal Design Define S Mid Tower Case Review. $89.99 for Window Version and $79.99 Retail Non-Window version reviewed by @TheModZoo.com Staffers @TheModMosquito & Captain Curry Sauce @JesseLamba
Motherboard compatibility: ATX / Micro ATX / Mini ITX
Drive bay capacity: 3 - 3.5” HDD positions (can also accommodate 2.5” units)
2 - Dedicated 2.5” SSD/HDD unit positions
7 - Expansion slots
PC Fan Cooling Ventilation & Radiator Options:
9, Fan positions (2 Fractal Design Dynamic GP14 140mm fans included) 8 fan positions on window model. Filtered fan slots in front and bottom
Front: 3 – 120/140 mm fans (included is 1 Fractal Design Dynamic GP14 fan, 1200 RPM speed)
Rear : 1 – 120/140 mm fan (included is 1 Fractal Design Dynamic GP14 fan, 1200 RPM speed)
Top: 3 - 120/140 mm fan (not included) or 1 - 180 mm fan with 165mm hole spacing (not included) Bottom 1 – 120/140 mm fan (not included) Side (non-window version only) 1 – 120/140 mm fan (not included)
Water cooling compatibility:
Radiators Front – 360, 280, 240, 140 and 120 mm radiators of all thicknesses
Top – 420, 360, 280, 240, 140 and 120 mm radiators. (A thickness limitation of 55mm for both radiator + fan applies on 420, 280 and 140 mm radiators)
Bottom: – 120 mm radiator (Use of radiators in the bottom position limits the PSU length to 165 mm)
Rear – 120 or 140 mm radiator Water cooling compatibility,
Pumps: Pre-drilled holes on the bottom panel, supports many DDC and D5 variants
Reservoirs: Adjustable mounting brackets allow for almost any rectangular mounting screw pattern. Maximum distance between the mounting bracket screw positions: 350mm height / 80mm width
Dust filters: Bottom and front intakes
CPU coolers up to 180 mm in height Front interface
2 USB 3.0 • Audio in/out• Power button with LED (blue)
HDD activity LED (blue)
Reset button
Power supply compatibility • ATX PSUs up to 180/170 mm with a bottom 120/140mm fan installed• When not using any bottom fan location longer PSUs up to 300mm can be used
Graphics card compatibility - Graphics cards up to 425 mm in length with front fans installed, without compromising HDD capacity. With a front radiator, maximum graphics card length is reduced by the radiator thickness
Additional information - 20-40 mm of space for cable routing behind the motherboard plate. Velcro straps included for easy cable management. Both side panel features smart captive thumbscrews.
This new PC case design blends the appearance, sound dampening technology, and support for a wide variety of compo-nents from the widely popular Define Series, while introducing a new, innovative internal layout. The Define S case is packed with intelligently designed enthusiast-oriented features delivering a silent case with powerful and expansive air and liquid cool-ing support, presented in a stunning Scandinavian inspired construction.The modernized internal layout of the Define S omits the optical drive bays, instead focusing on a clear straight airflow path and uncompromising water cooling support.The Define S case reaches the highest level of silent computing through strategically placed dense sound-absorbing material, multiple ModuVent™ fan vent covers and finely tuned Dynamic Series fans.
